Cast-in-situ Bridge Formwork Support System
Bridge Formwork System fits curved & folded‑line beams, features rapid pre‑assembly, adjustable high‑strength frame, movable supports, pedestrian passage, compatible with disc‑lock scaffolding.
High-strength channel steel is adopted as main beams.
Adjustable steel props bear all loads from flange formwork, reinforcing steel bars and concrete pouring.
These adjustable steel props can extend, retract and rotate to adjust the position and angle of flange main beams, adapting to various flange profiles.
Therefore, the system can be reused cyclically in the construction of all types of cast-in-place girders.
