Cantilever Form Traveller (CFT)
Cantilever Casting Universal Classic Solution. The main load-bearing structure is positioned above the bridge deck, offering clear structural force distribution, high rigidity, and easy installation.
Ultimate Safety
Real-time stress monitoring and early warning for main load-bearing components;
Self-synchronizing during travelling and jacking operations ensures zero overturning risk;
Dedicated project supervisors conduct regular on-site inspections for timely hazard identification;
100% inspection of components after returning to factory to guarantee structural safety and reliability;
Comprehensive protection system ensures worry-free on-site operations.
Rapid Delivery
Three warehousing bases located in Hunan, Sichuan and Anhui, with a total service capacity for over 1,000 T-frame equipment units, enabling rapid response to project demands.
Type | Technical Parameters | |
|---|---|---|
Parameter | Value | |
Scope of Application | Max. Segment Length | 6 m |
Max. Segment Weight | 500 t (for single-cell box girder condition) | |
Number of Box Cell | Single-cell box girder, multi-cell box girder | |
Max. Applicable Longitudinal Gradient | 4% | |
Wireless Remote Transmission Range | 5 km | |
Safety Features | Force Balancing Method | Self-anchored and well-balanced, low/no overturning risk |
Anchorage Safety Factor | ≥ 2 | |
Anti-overturning Safety Factor | ≥ 2 | |
Total Installed Power | 11 kW | |
Operational Convenience | Applicable Range of Main Members | Suitable for 95% of cast-in-place cantilever bridges |
Travelling Speed | 0.1 m/min, one-touch hydraulic travelling | |
